THE VEEM SURF SERIES - SPECIAL PRE-ORDER PROPELLER
The VEEMSurf propeller is the latest in surface piercing
propeller design. It is loaded with design innovations including the VEEM
Interceptor™ technology that makes it unbeatable when seriously high thrust
must be applied in a smooth, quiet and reliable manner. Using ‘shock-free’
blade sections and optimized blade area, you can rely on smooth operation in
any condition.
- VEEM’s unique parabolic rake blades for reduced wash
- Shock free blade section design for maximum smoothness
- Choice of medium speed or very high-speed blade sections
- Ability to custom design rake, skew, thickness and camber
- CFD optimized blade thickness for maximum strength and
durability
- Radially optimized blade thrust
- Minimum manufacturing accuracy of ISO 484/2 Class S
- VEEM’s robotic high luster polished blade surface
- ISO 1940/1 G2.5 (gas turbine) high accuracy dynamic balancing
VEEM SURF Propeller standard features include:
- Full Taper Hub Length
- ISO Class-S
- Puller Holes
- Anti-Sing edges
- Dynamically Balanced
- Interceptor Technology
- NiBral Alloy (Nickel Aluminum Bronze)
- Custom Pre-Order Propellers available in as little as 4 weeks to your door.
Diameter: | 20" to 61" |
Pitch
Distribution: |
Variable
Pitch |
Blade
Section Type: |
Cambered/Cleaver |
Skew: |
35 Degrees |
Blade
Rake: |
10 Degrees |
Material: |
NiBrAl
(Nickel Aluminium Bronze) |
Manufacturing
Standard: |
ISO
484/2 Class S |
Design Speeds: | 18 to 50 Knots |
